晶片原廠：原相科技
原相的光學動態追蹤 (OMT) 技術利用專有的影像感測核心技術來連續捕捉、處理和分析動態影像，直接輸出相對 X 和 Y 的位移數據，PAA3905將影像處理和分析都整合到感測器中，無需使用任何外部 ISP 及演算法，從而減少了複雜影像分析的開發工程。PAA3905 感測器具有低功耗及高幀率的架構，可快速在80mm以上的工作距離範圍內偵測到的XY位移量並即時回應給主控制器及支援更長的連續工作時間。PAA3905封裝與其搭配鏡頭組裝起來的感光組合，體積小、重量輕，最適合空間受限及對輕量型產品設計。 PAA3905 OMT 感測器是光流導航的絕佳選擇，可為在 GPS 訊號較弱的室內區域或黑暗、封閉空間中飛行的無人機提供相對位移數據，用於穩定機體和運用為飛行路徑追蹤。
晶片原廠：瑞昱半導體
HUB 8735 Smart AI CAM是具備多功能影像處理的高度集成模組，內置NPU AI 運算引擎，加速處理AI模型以及802.11 a/b/g/n 雙頻Wi-Fi與BLE低耗電藍牙傳輸，可廣泛應用於各種結合影像識別或 AI運算之物聯網場域，適用於智能家庭，工業物聯網，智慧零售，健康照護或是車用電子等場景；多款Pre-trained AI models已最佳化在模組直接運行，可做 為AI教學之體驗工具；同時尺寸僅30.5x43.9mm，亦為可直接整合在產品設計中做為快速導入Edge AI應用的快製套件。
Chip：MediaTek
Official website：https://www.mediatek.tw/
MediaTek Filogic 130 (MT7933/MT7931) is an SoC (system on a chip) that integrates an Arm Cortex-M33 MCU, connectivity subsystems like Wi-Fi 6 and Bluetooth 5.2, a power management unit (PMU), and optional audio DSP using the latest standards to provide reliable network connectivity and data transfer for greater energy efficiency but in a smaller size. The optional audio DSP is super ideal for product developers who are designing voice-enabled IoT devices.
晶片原廠：瑞昱半導體
HUB5168+除了延續DSI5168輕薄短小、完整兼容Arduino開發特性等優點之外，新增加了支援2.4G/5G雙頻Wi-Fi、低功耗藍牙BLE5.0及雙核心處理器，結合(I/O)擴充模組可直上OLED，還有更多I/O可運用，是物聯網產品開發的好工具。
Chip：Coretronicmems
Official website：https://www.coretronicmems.com/
CoreMaker-01 adopts Nuvoton M484, with Arm® Cortex®-M4F as the core and a high-performance, low-power-consumption microcontroller with a DSP instruction set. It also supports programmable interfaces like UART, SPI, and I²C. Developers can use the ARM Mbed IoT device platform, a one-stop integrated solution that combines Internet protocol, security, and standardized management, specifically designed for IoT devices that are sensitive to power consumption and pricing.
Through a multi-dimensional sensing module, a cost-effective AIoT solution is created with the concept of “Device AI”. With this solution, you can develop AI models on your own or via CMC, and then burn them into the CoreMaker-01 MCU to create an AI device.
TeraSilIC Electronics has AiM (Antenna-in-Module) and AiP (Antenna-in-Package) products and several general-purpose sensor development tools that are extremely cost-effective. The disruptive innovations brought by TeraSilIC’s most cost-effective CMOS radar sensors have led to a multitude of consumer smart applications. For example, in areas such as smart home appliances (air conditioning, bathroom, lighting control, voice-controlled assistant), smart monitoring (surveillance cameras), automation (hands-free tailgate release, road monitoring), energy use control, etc., the 24GHz multi-functional high-precision radar sensor will replace the old low-frequency sensors which are bulky and single-functional, and help developers enter the international smart living market estimated at an annual output value of more than US$100 billion per year.
Compatible with Arduino’s development environment
Pin design meets open-source requirements
DSI2599 is a product co-branded by Nuvoton & IoT Service Hub with its NuMaker-IoT-M487 EVB as the core, and built-in RJ45 Ethernet and Wi-Fi modules, allowing users to connect to the cloud in wired or wireless modes. Through different wireless daughter boards, it can provide connectivity via NB-IoT and 6LoWPAN to meet the needs of various application scenarios. DSI2599 provides Arduino Uno compatible interface, mikroBUS™ interface, NuMakerBrickI2C connector, and specific I/O connector, as well as multiple networking methods and interfaces, which can support image sensing, sound recording/playback, and flexible data space augmentation. With the data platform of IoT Service Hub, DSI2599 can either function as an endpoint device or a lightweight gateway application, proving itself as a great choice for novice programmers in the realm of IoT.
Based on the dual-core ARM® Cortex, DSI 5188 is an embedded 2.4GHz wireless connection solution which integrates Wi-Fi 802.11b and Bluetooth Smart® into one SoC (System on a Chip). Compared with solutions that only support a single communication protocol, DSI 5188’s ground-breaking architecture which supports Wi-Fi and Bluetooth, baseband and MAC, consumes the lowest power yet yields the highest performance with the lowest system cost. In addition, it provides a scalable network, making it easier and more flexible to design interconnected IoT systems or connect to the cloud.
DSI2598+ adopts the NB-IoT chip MT2625 module by MediaTek, based on the STM32 F103 core. This simple but complete option has pin functions such as PWM, I2C, SPI, ADC, UART, etc. with excellent computing capabilities, allowing users to seamlessly connect to most Arduino program libraries and develop various functional programs. The size of DSI2598+ is only 6x3cm, and is the first small-scale NB-IoT EVB in Taiwan.
Can assist in the rapid development and production of smart home appliances and AIoT edge devices enabled by smart monitoring.
Chip：Himax
Official website：https://www.himax.com.tw/zh/
Himax WE-I Plus development board is your best solution for its ultra-low power consumption and high performance according to the application goals of “TensorFlow Lite for Microcontrollers”. It integrates comprehensive features such as AoS™ VGA sensor, L/R stereo microphone, three-axis accelerometer, USB, SPI/I2C bridge, etc. on a 40mmx27mm circuit board, and offers a complete SDK to help you effectively process sensory information data captured by image, voice, or analog environmental sensors by using machine learning technology.
DSI5168 is a very convenient development tool for makers. It includes the RTL8711AM wireless module and an integrated programming tool, fully compatible with Arduino’s development features and integrating high-performance MCU, Wi-Fi, Ethernet and rich peripheral equipment. It provides a standard Arduino library to assist developers and makers to devise a complete set of IoT solutions.
